150kV Cable Derating Studies<br/><span class="design1">(Specialist Studies)</span>
End User Vinci Energies, Greece Project Title 150kV Cable Derating Studies (Specialist Studies) Year 2021 Project Scope The client has constructed boreholes for two 150kV 800 mmsq cable circuit using Horizontal Directional Drilling (HDD). However, there is a section where the boreholes were coming too close and that it could impact the current capacity of […]
Isle of Grain 400kV Synchronous Compensator<br/><span class="design1">(Owners Engineer)</span>
End User Uniper Energy Client SSE Enterprise Project Title Isle of Grain 400kV Synchronous Compensator (Owners Engineer) Year 2021/22 Project Scope Installation of 2 Synchronous Compensator 4A and 4B at Isle of Grain power station in Kent. The Synchronous Compensator is connected to existing 400kV National Grid Grain substation. Our Scope UKPE is engaged to […]
TP141 Settings Calculations and Verification for Iver 400/275kV SGT6A and 6B<br/><span class="design1">(Specialist Support)</span>
End User National Grid Client GE Vernova Project Title TP141 Settings Calculations and Verification for Iver 400/275kV SGT6A and 6B (Specialist Support) Year 2023 Project Scope The scope covers preparation of TP141 calculations and verifications undertaken by 2 independent authorised TP141 Engineers. Our Scope This scope includes: Review of suppliers’ design drawings Review of supplier […]
Replacement of 132kV Outdoor CB at Melksham Substation<br/><span class="design1">(Concept and Detailed Design)</span>
End User SSEN South Client KUS Power Engineering Project Title Replacement of 132kV Outdoor CB at Melksham Substation (Concept and Detailed Design) Year 2023 Project Scope Replacement of the existing 132kV SF6 outdoor circuit breaker A105 (Frome 2 Circuit) at Melksham 132/33kV substation and provision of a new protection panel and interfacing with existing protection […]
Design and Project Services Framework Contract (RIIO-2)<br/><span class="design1">(Design ASSURANCE)</span>
Client National Grid Project Title Design and Project Services Framework Contract (RIIO-2) (Design Assurance) Year 2022 to 2026 Project Scope UKPE is providing design assurance services to National Grid for their projects under the RIIO-2 framework and currently offering assurance services for the following disciplines: Lead Design Engineer HV Design Protection & Settings HVDC & […]
Biggleswade 400/132kV Substation<br/><span class="design1">(design verification and technical support)</span>
End User National Grid Client Omexom Project Title Biggleswade 400/132kV Substation (Design Verification And Technical Support) Year 2023/24 Project Scope To design, supply, construct, install and commission the new 400kV Biggleswade substation to enable the demand connection of 80MW to supply UKPN. The project scope includes, but is not limited to, the design, supply, construction, […]
Protection schemes design for 132/33kV grid substation<br/><span class="design1">(Detailed Design)</span>
Client UK Power Networks Project Title Protection schemes design for 132/33kV grid substation (Detailed Design) Year 2020 to 2026 Project Scope Provided detailed design for protection secondary scheme for connection projects involving 132kV grid substations. Warley 132kV Grid substation Shenfield 132kV Grid substation Rivenhall 132kV Grid substation Braintree 132kV Grid substation Our Scope Conduct site […]
Project development services framework contract<br/><span class="design1">(specialist studies)</span>
Client SP Energy Networks Project Title Project development services framework contract (Specialist Studies) Year 2021 to 2025 Project Scope Providing protection relay settings engineering for capital and green recovery projects under ED2. The project involves 15 GSP sites. Our Scope Perform settings calculations, grading studies (upper and lower stream relays), provide associated fault study […]
Protection schemes design for 33/11kV primary substations<br/><span class="design1">(Concept and Detailed Design)</span>
Client UK Power Networks Project Title Protection schemes design for 33/11kV primary substations (Concept and Detailed Design) Year 2020 to 2026 Project Scope Undertake conceptual and detailed design for protection secondary scheme design for various capital and connection projects involving 33/11 Primary substations. 33/11kV transformer load blinding and HV replacement scheme for 25 primary substations […]
Overhead Line (OHL) connection design schemes from 33kV to 132kV<br/><span class="design1">(Concept and Detailed Design)</span>
Client UK Power Networks Project Title Overhead Line (OHL) connection design schemes from 33kV to 132kV (Concept and Detailed Design) Year 2020 to 2026 Project Scope Undertake feasibility studies, conceptual and detailed design. The studies include tower structural assessment, clearance assessment, tower member replacement design, foundation assessment, insulator assessment, checking temperature infringements, tower modeling in […]
